JQ16-32-2VS Double-Reel Coiling Machine
High-efficiency double-station pipe coiler for 16-32 mm PE pipes, with dual-reel alternating operation, Delta control and up to 35 m/min coiling speed.
Function
Double-reel coiling
Range
16-32 mm
Line
PE pipe
Plastic Pipe Winding Machine
Pipe winding and coiling machines collect flexible PE, PPR and corrugated pipe after extrusion with single-station, double-station and automatic configurations.
JQ16-40-2VS Double-Reel Coiling Machine
Opposite double-station PE pipe coiler for 16-40 mm pipes, with balanced dual-reel structure, ultrasonic speed tracking and Delta HMI control.
Function
Double-reel coiling
Range
16-40 mm
Line
PE pipe
JQ20-63-1VS Single-Reel Coiling Machine
Economical single-station pipe coiler for 20-63 mm PE pipes, with Delta servo control, pneumatic unloading and adjustable coil size.
Function
Single-reel coiling
Range
20-63 mm
Line
PE pipe
JQ40-63-2VS Double-Reel Coiling Machine
Double-station PE pipe coiler for 40-63 mm pipes, with Delta servo control, ultrasonic speed tracking and pneumatic auxiliary functions.
Function
Double-reel coiling
Range
40-63 mm
Line
PE pipe
JQ50-125 Manual Inner Diameter Single-Reel Coiling Machine
Single-station pipe coiler for 50-125 mm PE pipes, with manually adjustable coil inner diameter, Delta servo traverse system and pneumatic unloading.
Function
Manual ID coiling
Range
50-125 mm
Line
PE pipe
JQ50-125-1VS Single-Reel Coiling Machine
Single-station PE pipe coiler for 50-125 mm pipes, with electric coil inner diameter adjustment, Delta intelligent control and pneumatic auxiliary functions.
Function
Electric ID coiling
Range
50-125 mm
Line
PE pipe
JQ75-160-1VS Single-Reel Coiling Machine
Single-station PE pipe coiler for 75-160 mm pipes, with electric inner diameter adjustment, Delta control and heavy-load winding support.
Function
Single-reel coiling
Range
75-160 mm
Line
PE pipe
JQ76-225 Coiler and Uncoiler Machine
Coiler and matching uncoiler system for 76-225 mm PE coiled pipes, with electric coiler inner diameter adjustment and heavy-duty unwinding support.
Function
Coiler + uncoiler
Range
76-225 mm
Line
PE pipe
JQ90-250 Single-Reel PE Pipe Coiler
Heavy-duty single-reel PE pipe coiler for 90-250 mm pipes, with electric inner diameter adjustment, electric winding width adjustment and 4000 mm maximum coil outer diameter.
Function
Heavy-duty coiling
Range
90-250 mm
Line
PE pipe
